Just moved with a Kenmore 417.44102300 Motor may be shot  Rate Topic
AuthorPost
 Posted: Tue Nov 16th, 2010 11:14 pm
  PM Quote Reply
1st Post
Vincentpghpa
Grasshopper


Joined: Tue Nov 16th, 2010
Location:
Posts: 2
Flavorite Brew:
Status:
Offline
I have the kenmore front loading model number 417.44102300

We just moved from San Diego to Washington and when we hooked it up the new sound is when the barrel starts moving the motor has a grinding noise. (At least I think it's from the motor) When the barrel goes faster then the grinding gets more high pitched.

After extensive reading through these very forums I think it quite possibly be a broken fan blade in the motor if there is a fan. if not then it just means the motor needs replaced.


There is also a new noise when the barrel is moving. There is some kind of squeaking/chunking noise when the barrel changes changes direction or in it's faster versions or modes.

in the front of the machine, there are those support things that aren't in the diagrams. One (the front right) was missing a washer that separates the 2 lock nuts. I put one on and the squeaking lessened but the chunking got worse.

The machine also dances when it's in the final phase of the spin cycle but I was hoping that the washer that I put on fixes that problem. It didn't.

I was able to make sure the machine is level thinking that may be the problem but that isn't it. At least I don't think it is.

Back To Top PM Quote Reply

 Posted: Tue Nov 16th, 2010 11:26 pm
  PM Quote Reply
2nd Post
Vincentpghpa
Grasshopper


Joined: Tue Nov 16th, 2010
Location:
Posts: 2
Flavorite Brew:
Status:
Offline
After running it through a cycle with the bottom panel I am wondering if those support things weren't in the diagram because they aren't supposed to be in the machine unless it's being transported. There was a dude that came out before the move to make sure the washer was ready to be moved and installed a bunch of stuff. The movers just might have not removed everything like he should have.


Oh one more thing, we also used it as a stackable washer/dryer combo when we lived in San Diego. We no longer can and we may be missing hardware but my wife is pretty good with not losing stuff like that. How do you intstall the cover on the top of the washer.

Back To Top PM Quote Reply

 Posted: Wed Nov 17th, 2010 12:31 am
  PM Quote Reply
3rd Post
RegUS_PatOff
Fellow, Academy of Sublime Masters of Appliantology


Joined: Sat Sep 24th, 2005
Location: Milwaukee, Wisconsin USA
Posts: 16509
Flavorite Brew: Indian Head. Black & White
Status:
Offline
Frigidaire Kenmore 417.44102300 Parts List & Diagrams

see PDF page 4
417.44102300 Installation Instructions


Shipping Support




____________________
The new repair forums==> http://appliantology.org
Back To Top PM Quote Reply

 Posted: Wed Nov 17th, 2010 06:58 am
  PM Quote Reply
4th Post
BrntToast
Fellow, Academy of Sublime Masters of Appliantology


Joined: Wed Mar 14th, 2007
Location: Winnipeg, Manitoba Canada
Posts: 1088
Flavorite Brew: MGD
Status:
Offline
reg posted the instructions for installation, short answer, yes... those yellow braces get removed, there are also bolts in the rear if your shipper installed these as well

for the lid you need 2 brackets on the front of the washer that would have been removed when the dryer was stacked part# 131460900

the 2 brackets for the back of the lid are part#131668200 (these might still be attached to the back of the lid, on some models these reversed to be used as the rear dryer support brackets)

*important note*!!!! if you are missing the original screws make sure the screws you use for the front bracket are no longer than 1/2 inch

if a screw that is too long is used to attach the front bracket it will damage the parts below it!!!

Last edited on Wed Nov 17th, 2010 07:00 am by BrntToast



____________________
The only stupid question is the one not asked
hope i've been helpfull, if you wish to buy Brnt beer kick here

http://brnttoast.googlepages.com/home

feel free to prvt msg frigidaire questions my way
(i dont log in every day)
Back To Top PM Quote Reply
