| Posted: Sun Aug 15th, 2010 12:25 am |
|
1st Post |
|
RichieU Grasshopper
|
It all works great except it won't spin. All other motor functions work. It will rotate at the end but refuses to spin. It has been suggested elsewhere that it could be the speed control board. But I am a mere grasshopper so I sit in meditation until a wise one sees the anwser to my dilema and responds with great wisdom.
|
||||||||||||||
| |||||||||||||||
| Posted: Sun Aug 15th, 2010 12:30 am |
|
2nd Post |
|
RegUS_PatOff Fellow, Academy of Sublime Masters of Appliantology
|
Is there standing left water in the Drum ? any error codes / flashing lights ?
____________________ The new repair forums==> http://appliantology.org RegUS_PatOff http://www.youtube.com/watch?v=oPAY2LsKVEw my video production: “Easter Seals Walk With Me” http://www.youtube.com/watch?v=-EBiLyYXMiA |
|||||||||||||
| ||||||||||||||
| Posted: Sun Aug 15th, 2010 12:41 am |
|
3rd Post |
|
RichieU Grasshopper
|
Thanks for the quick reply!!!....the drum drains completely and no flashing codes....
|
||||||||||||||
| |||||||||||||||
| Posted: Sun Aug 15th, 2010 12:44 am |
|
4th Post |
|
RichieU Grasshopper
|
Oh yeah.....how do the codes appear?
|
|||||||||||||
| ||||||||||||||
| Posted: Sun Aug 15th, 2010 01:00 am |
|
5th Post |
|
RichieU Grasshopper
|
Ok....I am getting 3 signal beeps...
|
||||||||||||||
| |||||||||||||||
| Posted: Sun Aug 15th, 2010 01:10 am |
|
6th Post |
|
RegUS_PatOff Fellow, Academy of Sublime Masters of Appliantology
|
and flashing lights ? Frigidare GE WSSH300G0WW Tech Sheets
____________________ The new repair forums==> http://appliantology.org RegUS_PatOff http://www.youtube.com/watch?v=oPAY2LsKVEw my video production: “Easter Seals Walk With Me” http://www.youtube.com/watch?v=-EBiLyYXMiA |
|||||||||||||
| ||||||||||||||
| Posted: Sun Aug 15th, 2010 01:16 am |
|
7th Post |
|
RichieU Grasshopper
|
I am running it again on the spin cycle to look for lights...be back soon !!
|
||||||||||||||
| |||||||||||||||
| Posted: Sun Aug 15th, 2010 01:20 am |
|
8th Post |
|
RichieU Grasshopper
|
Ok ...just finished the spin cycle ...it ends with 3 signal beeps 3 x's in succesion and no flashing lights...
|
|||||||||||||
| ||||||||||||||
| Posted: Sun Aug 15th, 2010 02:45 am |
|
9th Post |
|
RichieU Grasshopper
|
I referred to the tech sheet and it gave me a code of E46 which says to "Replace the control board." Have I obtained the knowlege of the wise one? Can this grashopper do the job?
|
||||||||||||||
| |||||||||||||||
| Posted: Sun Aug 15th, 2010 03:10 am |
|
10th Post |
|
RegUS_PatOff Fellow, Academy of Sublime Masters of Appliantology
|
which lights flash.. how many times ?
____________________ The new repair forums==> http://appliantology.org RegUS_PatOff http://www.youtube.com/watch?v=oPAY2LsKVEw my video production: “Easter Seals Walk With Me” http://www.youtube.com/watch?v=-EBiLyYXMiA |
|||||||||||||
| ||||||||||||||
| Posted: Sun Aug 15th, 2010 03:32 am |
|
11th Post |
|
RichieU Grasshopper
|
The five indicator lights of Door Lock, Wash, Rinse, Final Spin and Control flashed 4 x's and the Start indicator light flashed 6 x's.
|
||||||||||||||
| |||||||||||||||
| Posted: Sun Aug 15th, 2010 06:19 am |
|
12th Post |
|
appl.tech.29501 Fellow, Academy of Sublime Masters of Appliantology
|
According to the tech sheet that RegUS_PatOff posted , that would be code 46 "Replace Control Board"
____________________ If you would like to make a donation you may do so at the link below http://homepage.mac.com/zenzoidman/appl.tech.29501/ |
|||||||||||||
| ||||||||||||||
| Posted: Sun Aug 15th, 2010 09:52 am |
|
13th Post |
|
Budget Appliance Repair Fellow, Academy of Sublime Masters of Appliantology
|
appl.tech.29501 wrote: According to the tech sheet that RegUS_PatOff posted , that would be code 46 Not if the flashes aren't being counted correctly, this is a Frigidaire built F/L machine. Common problem with counting the flashing lights. The start light is flashing at the same time as the other row of lights and those first flashes may not be getting counted. If it tumbles OK then the motor/speed control board is most likely OK. You need to put it into the diagnostic cycle and if the high speed spin works in diagnostic cycle the motor/speed control board is OK. The most likely cause of the problem is a bad wax motor in the door latch/lock assembly.
____________________ William Burk (Willie) Willie's Budget Appliance Repair Eureka, CA 95501 |
||||||||||||||
| |||||||||||||||
| Posted: Sun Aug 15th, 2010 01:09 pm |
|
14th Post |
|
RegUS_PatOff Fellow, Academy of Sublime Masters of Appliantology
|
Budget Appliance Repair wrote: Not if the flashes aren't being counted correctly, this is a Frigidaire built F/L machine. right, for the correct Start Light digit count, you must count the total number of times the Start Light is flashing, including during the flashing of the other 5 lights.
____________________ The new repair forums==> http://appliantology.org RegUS_PatOff http://www.youtube.com/watch?v=oPAY2LsKVEw my video production: “Easter Seals Walk With Me” http://www.youtube.com/watch?v=-EBiLyYXMiA |
|||||||||||||
| ||||||||||||||
| Posted: Sun Aug 15th, 2010 06:59 pm |
|
15th Post |
|
RichieU Grasshopper
|
That is exactly how I determined the code........should I try the diagnostic anyway? Does the tech manual explain the diagnostic procedure?
|
||||||||||||||
| |||||||||||||||
| Posted: Sun Aug 15th, 2010 07:51 pm |
|
16th Post |
|
RichieU Grasshopper
|
The control board is showing up a part# WH20X10038 .....now some show it as a kit others show it as a single unit. The kit can run as high as 350.00 and the single unit which is mounted next to the motor is as low as $110.00. This grasshopper needs the wise words from a Master!!
|
|||||||||||||
| ||||||||||||||
| Posted: Sun Aug 15th, 2010 09:46 pm |
|
17th Post |
|
RegUS_PatOff Fellow, Academy of Sublime Masters of Appliantology
|
RichieU wrote: The control board is showing up a part# WH20X10038 ..... that would be the Speed Control Board .. I think you want the Control Board GE WH42X10719 / WH42X10787 click on picture $ 250  OR the Frigidaire equivalent 134732918 / 137005000 click on picture $ 138
____________________ The new repair forums==> http://appliantology.org RegUS_PatOff http://www.youtube.com/watch?v=oPAY2LsKVEw my video production: “Easter Seals Walk With Me” http://www.youtube.com/watch?v=-EBiLyYXMiA |
||||||||||||||
| |||||||||||||||
| Posted: Mon Aug 16th, 2010 02:32 am |
|
18th Post |
|
RichieU Grasshopper
|
Ok my master...I have done wrong. I just ran the diagnostic and everything ran well including the spin. I somehow missed the code by one and the code is officially E47 which reads according to the GE tech sheet says; Board thinks the door PTC circuit is open in spin. Then it says to refer to test 9......which test 9 says 1. Remove the door lock assembly and measure the resistance of the PTC. The corrective action says Shorted or open. Defective door lock assembly. Reads around 1500 Ohms. Defective control board. So is it saying that the door lock assembly is dysfunctional due to the control board? Do I have to run my ohmmeter on the door lock assembly or do I simply replace the control board?
|
|||||||||||||
| ||||||||||||||
| Posted: Mon Aug 16th, 2010 04:36 am |
|
19th Post |
|
appl.tech.29501 Fellow, Academy of Sublime Masters of Appliantology
|
It's saying if the PTC is shorted or open then it's bad. It should read around 1500 ohms..if it does then it's good and the control board would be bad.
____________________ If you would like to make a donation you may do so at the link below http://homepage.mac.com/zenzoidman/appl.tech.29501/ |
||||||||||||||
| |||||||||||||||
| Posted: Mon Aug 16th, 2010 10:56 am |
|
20th Post |
|
Budget Appliance Repair Fellow, Academy of Sublime Masters of Appliantology
|
appl.tech.29501 wrote: It's saying if the PTC is shorted or open then it's bad. It should read around 1500 ohms..if it does then it's good and the control board would be bad. Not totally true Appl.tech.29501. The PTC can ohm out good and the wax motor can still be bad, I find many times the failure of the wax motor is the actually mechanical part part of the wax motor. The wax cartridge seal fails and the wax leaks out around the plunger so plunger can't overcome the spring pressure and extend correctly. The machine doing a high speed spin in diagnostic is enough to prove you have a bad door latch/lock assembly. Replace the complete door latch/lock assembly or take a look at this discussion thread for someone with the exact same problem and info about replacing just the wax motor in the door latch/lock assembly. http://applianceguru.com/forum2/26563-2.html Last edited on Mon Aug 16th, 2010 10:59 am by Budget Appliance Repair ____________________ William Burk (Willie) Willie's Budget Appliance Repair Eureka, CA 95501 |
|||||||||||||
| ||||||||||||||
