Here are the pictures.  The yellow circle shows what I believe blew up.  I believe that is a resistor.  You can see the corner missing and the burnt on the white of the LED housing.  The blue arrows show the circuit that went bad, the blue arrow with the "?" looks bad in picture, but it's back in dryer for now testing the timer out.  Which for what it's worth, turns on and off in the correct positions, but my wife told me that since the dryer stopped sensing dryness and advancing the timer, she has tried all settings and none advance.  I have the drier running for the past 15minutes to see if the 10min setting turns off.  Time to go check that....

Thanks for the help!
