Maytag Neptune MAH5500B Shroud and inner door  Rate Topic
AuthorPost
 Posted: Sat Sep 4th, 2010 06:20 pm
  PM Quote Reply
1st Post
rehab40
Grasshopper


Joined: Sat Sep 4th, 2010
Location:
Posts: 2
Flavorite Brew: My homebrew
Status:
Offline
I have a Maytag Neptune model MAH5500B, this morning while washing a cover we heard a loud rumble, bang,crash. My wife and i ran downstairs to see the washer had moved about a foot and a half and it was in the final spin. We held it in place until everything shut down. When we opened the front door we found two parts of the shroud, about 1/3 of the total, had broken off and they also ripped into both sides of the bottom of the inner door. The drum spins fine, no unusual sounds, and it also has back and forth movement with no resistance. So I don't know what caused the drum to hit the inner door, the cover was not caught between the shroud and door. So now the question. We are fairly handy, is the replacement of the shroud and inner door something we can do? Any helpful tips or tricks on the repair? I have attached two pictures to assist in my description.

http://s386.photobucket.com/albums/oo304/tudupas/Maytag%20washer/

tom

Back To Top PM Quote Reply

 Posted: Sat Sep 4th, 2010 11:56 pm
  PM Quote Reply
2nd Post
appl.tech.29501
Fellow, Academy of Sublime Masters of Appliantology


Joined: Sun Oct 7th, 2007
Location: South Carolina USA
Posts: 6784
Flavorite Brew: waffle house coffee
Status:
Offline
Do these look like the parts your needing? Are the first 2 numbers of your Serial # 10 ? Has the rubber door boot been cut?


Front Tub Cover W/ Seal Link




Inner Door Link




____________________
If you would like to make a donation you may do so at the link below

http://homepage.mac.com/zenzoidman/appl.tech.29501/
Back To Top PM Quote Reply

 Posted: Sun Sep 5th, 2010 12:03 am
  PM Quote Reply
3rd Post
rehab40
Grasshopper


Joined: Sat Sep 4th, 2010
Location:
Posts: 2
Flavorite Brew: My homebrew
Status:
Offline
Yes, they look just like the pictures you posted and yes the S/N begins wit 10. i did run the unit again, just to see what would happen and nothing. It ran without a hitch, so i have some time to order stuff. Almost forgot, the rubber seal did not get damaged.

tom

Back To Top PM Quote Reply

 Posted: Sun Sep 5th, 2010 12:26 am
  PM Quote Reply
4th Post
appl.tech.29501
Fellow, Academy of Sublime Masters of Appliantology


Joined: Sun Oct 7th, 2007
Location: South Carolina USA
Posts: 6784
Flavorite Brew: waffle house coffee
Status:
Offline
Not a bad job, remove the screws holding the dispenser cover to the top of the machine and the cover.

Remove the door from the machine and the screws on the other side of the door opening where the hinges would be if the door was reversed.

Remove item # 15


Unplug the door latch wires, remove the screws and remove the door latch.

Raise the top

Remove the door boot clamp from the shroud and remove the shroud.

Now's your chance to give the boot a good cleaning before you put it all back together.




____________________
If you would like to make a donation you may do so at the link below

http://homepage.mac.com/zenzoidman/appl.tech.29501/
Back To Top PM Quote Reply
